The DEWE3‑PA8‑RM is tailored for permanent integration into 19″ test racks where high channel count, precision, and modularity are critical. It supports up to 16 power phases using 8 user-configurable TRION(3) power modules. The system captures data at up to 10 MS/s per channel and logs waveforms gap-free at up to 1 GB/s—ideal for high-speed transient analysis and dynamic power quality evaluations.
In addition to power signals, the system supports synchronized acquisition of mechanical, electrical, and digital inputs, making it a complete mixed-signal measurement platform. This is crucial for applications such as inverter efficiency testing, e-mobility R&D, and powertrain validation.
For automation, the DEWE3‑PA8‑RM offers real-time data output with sub-4 ms latency and supports industrial protocols like SCPI and XCP. An optional front-end firmware mode enables control from remote hosts without running Windows locally.
Maintenance is simplified through front-facing access to module slots, fans, and filters. Transducer supply is integrated, powering up to 8 current sensors directly from the chassis.
